Bahco 50 Ton Air Hydraulic Bottle Jack BH4HP50

Bahco 50 Ton Air Hydraulic Bottle Jack BH4HP50

The Bahco BH4HP50 is a professional-grade 50-ton air hydraulic bottle jack designed for lifting heavy vehicles and industrial machinery. It offers dual pneumatic and hydraulic operation for efficiency and safety in demanding environments such as workshops, garages, and roadside service units.

Features:

• 50 Ton Capacity: Capable of lifting loads up to 50,000 kg.
• Dual Operation: Can be used with air pressure or manually via hydraulic pumping.
• Heavy-Duty Welded Construction: Ensures maximum strength, durability, and leak-free performance.
• Safety Valve: Built-in overload protection prevents piston over-extension.
• Corrosion-Resistant Finish: Hard-chrome plated piston rod for longer service life.
• Wide Operating Temperature Range: Performs reliably from -20°C to +70°C.
• Compact and Portable: Equipped with carry handles for easy transport.

Specifications:

• Model: BH4HP50
• Lifting Capacity: 50,000 kg (50 Ton)
• Minimum Height: 300 mm
• Maximum Height: 470 mm
• Overall Dimensions: 300 × 210 × 310 mm
• Operating Air Pressure: 6.9 – 8.3 bar
• Weight: 37 kg
• Type: Air / Hydraulic Bottle Jack
• Material: Heavy-duty steel construction

Applications:

• Suitable for heavy vehicle lifting such as trucks, buses, and construction machinery.
• Ideal for automotive workshops, fleet maintenance, and roadside recovery operations.
• Can be used for industrial maintenance and equipment lifting in manufacturing environments.
• Designed for both pneumatic and manual use, offering flexibility in field and workshop conditions.

Includes:

• 1 × Bahco BH4HP50 Air Hydraulic Bottle Jack (50 Ton Capacity)
• Built-in safety overload valve
• Welded steel base for stability
• Carrying handles for portability
• Air input connection for pneumatic operation
